CNC-612 / 612S 6-sided machining center 1. Crossbeam adopts through structure, boring operations on 6 sides are complete
SHARE

Description

Basic Info.
Model NO. CNC - 612/ 612S
Customized Customized
Condition New
Specification 5800x2840x2200
Trademark TQS
Origin Foshan, China
HS Code 84659500
Production Capacity 15 Sets / Month
Product Description

CNC-612 / 612S 6-sided machining center

Automatic 6-Sided Machining Center Six-Sided Drilling Machine with Double Drill Pack


1. Crossbeam adopts through structure, boring operations on 6 sides are completed at one time.2. In order to achieve various processing, the machine adopts the combination of the boring head (horizontal + vertical) and individual spindle.

SpecificationsModelCNC-612S / 612
Travel Distance on Axis & Max. positioning speedX-Axis5000mm & 130m/min
Y-Axis1500mm & 550m/min
Z-Axis90mm & 30m/min
U-Axis5000mm & 130m/min
V-Axis1200mm & 80m/min
W-Axis100mm & 30m/min
A-Axis1260mm & 30m/min
Z1-Axis90mm & 45m/min
Y2-Axis1500mm & 55m/min
Z2-Axis90mm & 30m/min
Processing RangeMax. processing width (vertical)1200mm
Min. processing width (vertical)36mm / 50mm
Max. processing length (vertical)5000mm
Min. processing length (vertical)250mm
Max. processing thickness (vertical)48mm
Boring headsVertical boring headsLower: 6pcs, upper: 24pcs / 12pcs
Horizontal boring heads16pcs / 8pcs
Boring heads motor rotating speed3400 r/min
Spindle power3.5kw x2 / 3.5kw
Engraving spindleSpindle typeEr25
Spindle rotating speed18000 r/min
OthersWorking bench height960mm
Total power25.85kw / 20.65kw
Voltage380v 50hz
Air pressure0.7-0.8Mpa
Total weight3900kg / 3500kg
Overall dimension5800x2840x2200


Automatic 6-Sided Machining Center Six-Sided Drilling Machine with Double Drill Pack

Automatic 6-Sided Machining Center Six-Sided Drilling Machine with Double Drill Pack

1. What's your guarantee? Which type of after-sale service can you provide to us?
For all the machines, we can offer a 1-year guarantee to our customers; for any parts damaged due to the quality issue, we will send the parts via DHL, FedEx, or air shipment urgently.
After-sale service: if you purchased our CNC nesting center or edge bander, and we don't have any dealer or agent in your region, we will send our engineer to your site for installation and training ( you should pay the round-trip flight ticket, salary of engineer- each day 100.00USD, also take charge of the local accommodation. ). Considering the situation, we can do the online training. Also any small issues, you can knock us online, we will offer rapid action to your concerns.
2. Which type of payment term can you accept? How could we keep our capital safe?
We can accept the T/T and L/C at sight. We have more than 10 years of exporting experience, so we know more about the capital safety concern of our customers. We will offer the video call or pictures to your side, during our loading, then you can check what we have done for the loading, if any cheating, then you can control your payment (T/T or L/C).
3. What is the leading time, if we did the payment to your side?
The leading time of most common machines will be 10-25 days after collecting the down payment/copy of L/C. Specially designed production will take a little bit longer time.
4. Can you accept some O.E. M service to us? or any other service could you do for us?
We have more than 15 years experience in the woodworking machinery industry, also have more than 5 experienced engineers, so we can do the special design according to your requirement.
Also, our exporting team has more than 10 years of experience in this field, so they can help you to purchase relevant products, parts, or tools, which can save your time and your cost.
